Wiring for dashcam from the overhead console

Discussion in '3rd Gen. Tacomas (2016-2023)' started by CheemsMcGoober88, Nov 27, 2022.

  1. Nov 27, 2022 at 12:17 PM
    #1
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    I'm trying to wire a 5v power supply inside the tss box as well as install a switch on it for my dash cam. Does anyone know which wires I should pull the power from?
    (edit, I decided to wire it from the overhead console. Any info on which wires to use from the wiring harness would be appreciated.)

    Last edited: Nov 27, 2022
  2. Nov 27, 2022 at 1:36 PM
    #2
    Sinagua

    Sinagua Beerdom Brewing - brewing in the shadows

    Joined:
    Feb 15, 2018
    Member:
    #244530
    Messages:
    177
    Gender:
    Male
    First Name:
    Rob
    Harrisburg, NC
    Vehicle:
    2019 OR DCSB, 2022 Accord Sport Hybrid
    Dobinsons Suspension, SOS sliders and slimline bumper, Smittybilt winch, Skinny Geolanders and a tune
    My4thTacoma, Boatman12 and cryptolime like this.
  3. Nov 27, 2022 at 1:40 PM
    #3
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
  4. Nov 27, 2022 at 1:57 PM
    #4
    cryptolime

    cryptolime Here to Help

    Joined:
    Dec 2, 2021
    Member:
    #383651
    Messages:
    2,468
    Gender:
    Male
    Wilmington, NC
    Vehicle:
    2021 SR 4x4 2.7L
    might be easier to just buy the adapter and install a switch onto it

  5. Nov 27, 2022 at 2:08 PM
    #5
    Fatback17

    Fatback17 Masshole

    Joined:
    Jun 13, 2010
    Member:
    #38868
    Messages:
    1,488
    Gender:
    Male
    First Name:
    Billy
    South of Boston, Massachusetts
    Vehicle:
    2020 TRD Pro MGM
    Curious, why would you want to turn it off?

    DES2009 and Tocamo like this.
  6. Nov 27, 2022 at 3:51 PM
    #6
    stftaco

    stftaco Well-Known Member

    Joined:
    Jul 10, 2022
    Member:
    #401070
    Messages:
    874
    Gender:
    Male
    Vehicle:
    22 MGM DCSB Tacoma TRD Sport
  7. Nov 27, 2022 at 4:34 PM
    #7
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    I want it wired to constant power so it can run while I'm parked but also want it on a switch so it's not on for extended periods of time draining the battery.

    Fatback17[QUOTED] likes this.
  8. Nov 27, 2022 at 4:42 PM
    #8
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    stftaco[QUOTED] likes this.
  9. Nov 27, 2022 at 4:58 PM
    #9
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    Now to find a wiring diagram for the overhear console

  10. Nov 27, 2022 at 4:59 PM
    #10
    kona61

    kona61 Well-Known Member

    Joined:
    Aug 13, 2018
    Member:
    #262732
    Messages:
    120
    Gender:
    Male
    First Name:
    J
    Vehicle:
    LR 2022 Tacoma TRD OR
    RCI Skids
    I was going to say that I'd avoid messing wit the TSS box. It seems like quite a high risk system to try and pull power from.

  11. Nov 27, 2022 at 5:07 PM
    #11
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    Indeed, doesn't seem to be much room in there either.
    Overhead console it is.

    kona61[QUOTED] likes this.
  12. Nov 27, 2022 at 8:14 PM
    #12
    stftaco

    stftaco Well-Known Member

    Joined:
    Jul 10, 2022
    Member:
    #401070
    Messages:
    874
    Gender:
    Male
    Vehicle:
    22 MGM DCSB Tacoma TRD Sport
    CheemsMcGoober88[OP] likes this.
  13. Dec 3, 2022 at 1:10 PM
    #13
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    Ok so I tested the wires assuming the upper right hand wire with the black stripe is the ground. The two pins marked in red are when I'm getting constant 12v with the vehicle off.

  14. Dec 4, 2022 at 1:38 PM
    #14
    CheemsMcGoober88

    CheemsMcGoober88 [OP] Well-Known Member

    Joined:
    Nov 17, 2022
    Member:
    #410915
    Messages:
    64
    Gender:
    Male
    Vehicle:
    2021 TRD Offroad
    I wired it to the overhead console harness and added a switch. Everything works fine so far. I also have a rear camera that I'll wire in the future. I'm thinking of pulling the wire straight back in the headliner instead of along the threshold.
    https://youtu.be/igsOmzw6YO8
